hansgrohe shower channels & drains
You can find high-quality and durable shower channels and drains from hansgrohe in a variety of designs in our online store.
Prod. no.:
56247670
Hansgrohe RainDrain Point complete set point drain 100 x 100mm, tileable on the back
- consists of: Point drain, installation set, factory pre-assembled sealing fleece, base body, siphon, construction protection cap- Pre-assembled sealing membrane- can be tiled on the back- Water trap height: up to max. 50 mm- Nominal diameter of connection: DN40- Outlet direction: pre-assembled horizontally, can be used vertically- Easy to clean surface- Height adjustable by 10 mm- Area of application: new build, renovation- Tile thickness: up to 18 mm- Removable odor trap- Rotatable and adjustable trap body- Easy to clean trap- Cover lifter enables easy removal of the ready-made set- Odour trap type: liquid- Minimum installation height 54 mm- Base body height: 54 mm- Siphon material: ABS- Installation type: free in the room- Simplified installation due to the shortenable trap- Cover material: stainless steel V2A (1.4301)- Suitable for primary drainage- black matt
Variants from €73.45*
Prod. no.:
56270670
Hansgrohe RainDrain Go complete set shower channel 500 tileable on the back for standard/flat installation
- consists of: Prefabricated shower channel set, traps, installation set, factory pre-assembled sealing fleece, cover lifter, hair trap strainer- Cover material: stainless steel V2A (1.4301)- Installation set material: stainless steel V2A (1.4301)- Pre-assembled sealing membrane- can be tiled on the back- Water trap height: 30 mm, 50 mm- Nominal diameter connection: DN40, DN50- Outlet direction: horizontal- Easy to clean surface- Height-adjustable by 15 mm- Drainage capacity flat installation: up to 31 l/min- Drainage capacity standard installation: up to 39 l/min- Area of application: new build, renovation- Tile thickness: up to 11 mm- Rotatable and adjustable trap housing- Easy-to-clean trap- Cover lifter enables easy removal of the ready-made set- Siphon material: ABS- Installation type: free-standing in the room- Depth of the tile recess: 12 mm- Choice of two different traps for standard or flat installation- Suitable for primary and secondary drainage
Variants from €213.75*
Prod. no.:
56036000
Hansgrohe RainDrain Match finished set shower channel 60cm
- Consists of: Design cover, height-adjustable frame, wall-mounting flange, Dryphon- chrome- easy to clean surface- easy adjustment to the tile thickness due to the height-adjustable frame (7 - 18 mm)- tileable on the back side, except glass finishes (-450 and -610)- area of application: new construction, renovation- tile thickness: up to 18 mm- suitable for any type of tile- Cover lifter enables easy removal of the finished set- type of odor seal: mechanical- mounting type: wall-mounted, free in the room- wall mounting possible- Depth of tile recess: 12 mm- material quality of cover: stainless steel 304 (1.4301)- suitable for primary and secondary drainage- frame width: 62 mm- grate width: 46 mm- suitable for Rainmaker Select products with glass finishes (-450 and -610)- necessary accessories: uBox universal complete set for standard installation (56022180) or for flat installation (56016180)- base body not included in delivery
Variants from €134.01*
Prod. no.:
56043000
Hansgrohe RainDrain Flex finished set shower channel 70cm shortenable
- Consists of: Design cover with removable insert, Dryphon- can be shortened on site- easy to clean surface- height adjustable by 10 mm- field of application: new construction, renovation- cover lifter enables easy removal of the finished set- with integrated slope- Type of odor seal: mechanical- Mounting type: two-sided- Material grade cover: stainless steel 304 (1.4301)- suitable for primary drainage- grate width: 60 mm- chrome- required accessories: base body shower channel for flat installation (01000180), base body shower channel for standard installation (01001180) or base body shower channel for vertical installation (01002180)- Base body not included in delivery
Variants from €220.38*
Prod. no.:
56029000
Hansgrohe RainDrain Rock prefabricated set shower channel 70cm shortenable and tileable
- Consists of: tileable cover, integrated cover lifter, Dryphon- frameless design- can be shortened on site- height adjustable cover- field of application: new construction, renovation- tile thickness: up to 40 mm- suitable for any type and thickness of tile- cover lifter enables easy removal of the finished set- easy cleaning- type of odor seal: mechanical- type of installation: free in the room, two-sided- overlength of 50 mm on both sides- can be shortened to a minimum of 600 mm- material quality cover: stainless steel 304 (1.4301)- suitable for primary drainage- grate width: 58 mm- necessary accessories: uBox universal complete set for standard installation (56022180) or for flat installation (56016180)- basic body not included in delivery
Prod. no.:
56252800
Hansgrohe RainDrain Corner complete set point drain 240/240 brushed stainless steel
- consists of: Point drain, cover lifter, factory-fitted sealing fleece- Cover material grade: stainless steel V2A (1.4301)- Pre-assembled sealing membrane- Water trap height: 50 mm- Nominal diameter of connection: DN40- Outlet direction: horizontal- Frameless design- Easy to clean surface- height adjustable by 10 mm- up to 45 l/min drainage capacity- Area of application: new build, renovation- Tile thickness: up to 18 mm- Suitable for any tile type and thickness- Removable odor trap- Rotatable and adjustable trap body- Easy to clean trap- cover lifter enables easy removal of the ready-made set- With integrated slope- Easy to clean- With removable hair strainer- Type of odor trap: liquid- Minimum installation height 54 mm- Installation type: wall-mounted- Simplified installation thanks to the shortenable trap- Suitable for primary drainage
Prod. no.:
56174800
Hansgrohe RainDrain Compact complete set shower channel 600mm for standard installation
- consists of: Prefabricated shower channel set, installation set, trap, cover lifter, factory-fitted sealing fleece- Pre-assembled sealing membrane- Water trap height: 30 mm, 50 mm- Nominal diameter of connection: DN50- Outlet direction: horizontal- Easy to clean surface- Height-adjustable installation set, height-adjustable cover- Area of application: renovation, new build- Tile thickness: up to 18 mm- Suitable for all tile types and thicknesses- Removable odor trap- Easy to clean trap- Cover lifter enables easy removal of the ready-made set- Type of odor trap: liquid- Height of base body: 50 mm- Siphon material: ABS- Installation type: free in the room- Cover material: stainless steel V2A (1.4301)- Suitable for primary drainage
Prod. no.:
56050000
Hansgrohe RainDrain Flex ready set shower channel 70cm shortenable, for wall mounting
- Consists of: Design cover with removable insert, Dryphon- can be shortened on site- easy to clean surface- height adjustable by 10 mm- field of application: new construction, renovation- cover lifter enables easy removal of the finished set- with integrated slope- Type of odor seal: mechanical- Type of installation: wall-mounted- material grade cover: stainless steel 304 (1.4301)- suitable for primary drainage- grate width: 60 mm- chrome- required accessories: base body shower channel for flat installation (01000180), base body shower channel for standard installation (01001180) or base body shower channel for vertical installation (01002180)- Base body not included in delivery
Variants from €220.38*
Prod. no.:
56010180
Hansgrohe RainDrain uBox universal installation set 60cm for shower channels
- Consists of: Stainless steel channel, factory pre-mounted sealing fleece, adjustable feet, tiling aid- suitable for all RainDrain Rock and RainDrain Match prefabricated sets- Area of application: new construction, renovation- incl. height-adjustable feet and tiling aid for installation- with integrated slope- Material grade installation set: stainless steel 304 (1.4301)- required accessories: base body shower channel for flat installation (01000180), base body shower channel for standard installation (01001180) or base body shower channel for vertical installation (01002180)- Shower channel not included in delivery
Prod. no.:
56246800
Hansgrohe RainDrain Point complete set point drain 100 x 100mm
- consists of: Point drain, installation set, factory pre-assembled sealing fleece, base body, siphon, construction protection cap- Pre-assembled sealing membrane- Water trap height: up to max. 50 mm- Nominal diameter connection: DN40- Outlet direction: pre-assembled horizontally, can be used vertically- Easy to clean surface- Height adjustable by 10 mm- Area of application: new build, renovation- Tile thickness: up to 18 mm- Removable odor trap- Rotatable and adjustable trap body- Easy to clean trap- Cover lifter enables easy removal of the ready-made set- Odour trap type: liquid- Minimum installation height 54 mm- Base body height: 54 mm- Siphon material: ABS- Installation type: free in the room- Simplified installation due to the shortenable trap- Cover material: stainless steel V2A (1.4301)- Suitable for primary drainage
Prod. no.:
56162800
Hansgrohe RainDrain Compact complete set shower channel 600mm for flat installation
- consists of: Prefabricated shower channel set, installation set, trap, cover lifter, factory-fitted sealing fleece- Pre-assembled sealing membrane- Water trap height: 30 mm- Nominal diameter of connection: DN40- Outlet direction: horizontal- Easy to clean surface- up to 27 l/min drainage capacity- Area of application: renovation, new build- Tile thickness: up to 18 mm- Suitable for all tile types and thicknesses- Removable odor trap- Easy-to-clean trap- Cover lifter enables easy removal of the ready-made set- Type of odor trap: liquid- Minimum installation height 43 mm- Base body height: 30 mm- Siphon material: ABS- Installation type: free in the room- Cover material: stainless steel V2A (1.4301)- Suitable for primary drainage
Prod. no.:
56163000
Hansgrohe RainDrain Compact complete set shower channel 600mm tileable, for flat installation
- Consists of: tileable cover, installation set, siphon, cover lifter, factory-fitted sealing fleece- Pre-assembled sealing membrane- Sealing water height: 30 mm- Nominal diameter of connection: DN40- Outlet direction: horizontal- Easy to clean surface- Height-adjustable installation set, height-adjustable cover- up to 27 l/min drainage capacity- Area of application: renovation, new build- Tile thickness: up to 18 mm- Suitable for all tile types and thicknesses- Removable odor trap- Easy-to-clean trap- Cover lifter enables easy removal of the ready-made set- Type of odor trap: liquid- Minimum installation height 43 mm- Siphon material: ABS- Installation type: free in the room- Depth of the tile recess: 12 mm- Cover material grade: stainless steel V2A (1.4301)- Suitable for primary drainage
Prod. no.:
56175000
Hansgrohe RainDrain Compact complete set shower channel 600mm tileable, for standard installation
- Consists of: tileable cover, installation set, siphon, cover lifter, factory-fitted sealing fleece- Pre-assembled sealing membrane- Nominal diameter of connection: DN50- Outlet direction: horizontal- Easy to clean surface- Height-adjustable installation set, height-adjustable cover- up to 37 l/min drainage capacity- Area of application: renovation, new build- Tile thickness: up to 18 mm- Suitable for all tile types and thicknesses- Removable odor trap- Easy-to-clean trap- Cover lifter enables easy removal of the ready-made set- Type of odor trap: liquid- Height of base body: 50 mm- Siphon material: ABS- Installation type: free in the room- Cover material: stainless steel V2A (1.4301)- Suitable for primary drainage
Prod. no.:
56186800
Hansgrohe RainDrain Allround complete set shower channel 700mm
- consists of: Finished shower channel set, installation set, factory pre-assembled sealing fleece, cover lifter, siphons- Sealing membrane in 1300 x 1500 mm for complete sealing of the entire wet area- Nominal diameter connection: DN40, DN50- Outlet direction: horizontal- Easy to clean surface- Height-adjustable installation set- Drainage capacity flat installation: up to 50 l/min- Drainage capacity standard installation: up to 48 l/min- Area of application: new build, renovation- Rotatable and adjustable trap body- Easy-to-clean trap- cover lifter enables easy removal of the prefabricated set- With removable hair strainer- Type of trap: liquid- Installation type: free-standing in the room- Choice of two different traps- Cover material grade: stainless steel V2A (1.4301)- Suitable for primary drainage
Prod. no.:
56196800
Hansgrohe RainDrain Original shower channel 600mm
- consists of: Finished shower channel set, installation set, Dryphon, sealing fleece, cover lifter- Frameless design- Easy to clean surface- height-adjustable by 10 mm- up to 49 l/min drainage capacity- Area of application: renovation, new build- Tile thickness: up to 18 mm- Cover lifter enables easy removal of the prefabricated set- Odor trap type: mechanical- Dryphon enables waterless trap system- Installation type: free-standing in the room- Installation on the screed- Cover material: stainless steel V2A- Base body for installation (not included in the scope of delivery): 01001180 for standard installation; 01000180 for flat installation; 01002180 for vertical installation)
Prod. no.:
56261800
Hansgrohe RainDrain Flex prefabricated set shower channel 1600 can be shortened
- Perfect look: RainDrain Flex designer shower channel- Design freedom: height-adjustable and shortenable shower channel for installation flush with the wall on both sides- Robust and hard-wearing: the cover is made of high-quality stainless steel 304 (1.4301)- Scope of delivery: Fixing materials, installation instructions, shower channel finishing set, cover lifter, sealing fleece- Flexible: For sealing water height 30 mm (flat installation) or sealing water height 50 mm (standard) required base body: #01000180 or #01001180- hansgrohe Dryphon is the revolutionary trap solution with a high drainage capacity, even for large showers- Safe installation: Installation takes place on a separately available base body with pre-assembled sealing fleece- Floor-level shower: height-adjustable installation for a barrier-free shower area- Premium materials are used in all components - for greater safety and sustainability in the home- hansgrohe since 1901 - the premium brand for reliable bathroom and kitchen products- 5-year voluntary manufacturer's guarantee on a product manufactured to the highest quality standards
Prod. no.:
56055800
Hansgrohe RainDrain Spot Point Drain
- Consists of: Design cover, base body, siphon, factory pre-assembled sealing fleece.- sealing water height: 50 mm- Nominal diameter connection: DN50- direction of outlet: horizontal/vertical- easy to clean surface- height adjustable cover- field of application: new construction, renovation- removable siphon- rotatable and adjustable siphon housing- easy to clean siphon- type of odor seal: liquid- minimum construction height 68 mm- pre-mounted sealing membrane- material siphon: ABS- mounting type: free in the room- Material cover: stainless steel 304 (1.4301)- grate width: 146 mm
Prod. no.:
56262800
Hansgrohe RainDrain Flex prefabricated set shower channel 1600 can be shortened for wall mounting
- Perfect look: RainDrain Flex designer shower channel- Design freedom: height-adjustable and shortenable shower channel for installation flush with the wall on three sides- Robust and hard-wearing: the cover is made of high-quality stainless steel 304 (1.4301)- Scope of delivery: Fixing materials, installation instructions, shower channel finishing set, cover lifter, sealing fleece- Flexible: For sealing water height 30 mm (flat installation) or sealing water height 50 mm (standard) required base body: #01000180 or #01001180- hansgrohe Dryphon is the revolutionary trap solution with a high drainage capacity, even for large showers- Safe installation: Installation takes place on a separately available base body with pre-assembled sealing fleece- Floor-level shower: height-adjustable installation for a barrier-free shower area- Premium materials are used in all components - for greater safety and sustainability in the home- hansgrohe since 1901 - the premium brand for reliable bathroom and kitchen products- 5-year voluntary manufacturer's guarantee on a product manufactured to the highest quality standards
Prod. no.:
56112800
Hansgrohe RainDrain Spot point drain tileable on the back side
- Consists of: Design cover, base body, siphon, factory pre-assembled sealing fleece.- sealing water height: 50 mm- Nominal diameter connection: DN50- direction of outlet: horizontal/vertical- frameless design- easy to clean surface- height adjustable cover- field of application: new construction, renovation- suitable for any type and thickness of tile- removable siphon- rotatable and adjustable siphon housing- easy to clean siphon- type of odor seal: liquid- minimum height 78 mm- pre-mounted sealing membrane- material siphon: ABS- Mounting type: free in the room- Material cover: stainless steel 304 (1.4301)- grate width: 146 mm
Prod. no.:
56250670
Hansgrohe RainDrain Brilliance complete set point drain 100 x 100mm, tileable on the back
- Base body, factory pre-assembled sealing fleece, cover lifter, siphon, protective building cap- Pre-assembled sealing membrane- can be tiled on the back- Water seal height: up to max. 50 mm- Nominal diameter of connection: DN50- Outlet direction: horizontal- Easy to clean surface- Easy adjustment to the tile thickness thanks to the height-adjustable frame (7 - 18 mm)- Area of application: new build, renovation- Removable odor trap- Rotatable and adjustable trap housing- Easy-to-clean trap- Cover lifter enables easy removal of the prefabricated set- Odour trap type: liquid- Minimum installation height 79 mm- Base body height: 59 mm- Siphon material: ABS- Installation type: free in the room- Simplified installation due to the shortenable trap- Depth of the tile recess: 12 mm- Cover material: stainless steel V2A (1.4301)- Suitable for primary and secondary drainage- matt black
Variants from €212.86*
Prod. no.:
56226800
Hansgrohe Complete set of RainDrain Spot Plus point drains
- consists of: Design cover, base body, siphon, factory pre-assembled sealing fleece, construction protection cap- Cover material grade: stainless steel V2A (1.4301)- Pre-assembled sealing membrane- Water trap height: 50 mm- Nominal diameter connection: DN40- Outlet direction: pre-assembled horizontally, can be used vertically- Easy to clean surface- Height adjustable by 10 mm- up to 35 l/min drainage capacity- Area of application: new build, renovation- Removable odor trap- Rotatable and adjustable trap body- Easy to clean trap- Type of odor trap: liquid- Minimum installation height 95 mm- Siphon material: ABS- Installation type: free-standing in the room- Can be tiled on the back- Depth of the tile recess: 12 mm
Prod. no.:
56225800
Hansgrohe Complete set RainDrain Spot point drain
- consists of: Design cover, base body, siphon, factory pre-assembled sealing fleece, construction protection cap- Cover material grade: stainless steel V2A (1.4301)- Pre-assembled sealing membrane- Water trap height: 50 mm- Nominal diameter connection: DN40- Outlet direction: pre-assembled horizontally, can be used vertically- Easy to clean surface- Height adjustable by 10 mm- up to 35 l/min drainage capacity- Area of application: new build, renovation- Removable odor trap- Rotatable and adjustable trap body- Easy to clean trap- Type of odor trap: liquid- Minimum installation height 80 mm- Siphon material: ABS- Installation type: free-standing in the room
